Cabinet Centrifugal Fan Series: 2,000-25,000 m3/h

Compare cabinet centrifugal fans by 2,000-25,000 m3/h airflow, 400-740 Pa pressure, 220/380 V options and 55-79 dB noise.

Model Air Cabinet Fan Series

Core Parameters

Air Volume Range2000 – 25000 m³/h (depending on model) Static Pressure Range400 – 740 Pa Motor Power780 – 7856 W (depending on model) Power Supply Options220V/50Hz or 380V/50Hz

Key Features

Archimedes spiral air duct optimization for smoother airflow and more stable pressure All-metal housing with nano-coating for rust and corrosion resistance, suitable for long-term continuous operation Pure copper motor with double ball bearings, IP54 protection rating for extended durability Tool-free access port for easy maintenance and filter replacement

Applications

Electrical cabinets

Factory

HVAC equipment rooms

Technical Parameters

The MIWIND cabinet centrifugal fan series is built for ducted supply and exhaust applications that need more pressure than a basic axial fan. The listed range covers 2,000-25,000 m³/h airflow, 400-740 Pa pressure, 220 V and 380 V options, and approximately 55-79 dB noise depending on model and operating point.

Cabinet Centrifugal Fan Selection

Select the model from the required airflow at the connected static pressure. Include filters, grilles, dampers, heat exchangers, bends and duct length in the pressure calculation. The free-air maximum is not the delivered airflow after the fan is installed.

Voltage / frequency	Model range	Air volume (m³/h)	Pressure (Pa)	Noise (dB)
220 V / 50 Hz	Cabinet series 220 V models	2,000-4,100	410-460	55-65
380 V / 50 Hz	Cabinet series 380 V models	2,000-25,000	400-740	55-79

Listed Model Data

Model	Volt/Hz (V~/Hz)	Power (W)	Air volume (m³/h)	Pressure (Pa)	Speed (rpm)	Noise (dB)	G.W. (kg)
KTJ25-20(D)	220/50	780	2,000	430	1340	55	28.4
KTJ25-26(D)	220/50	805	2,600	410	1340	56	28.4
KTJ23-31(D)	220/50	1150	3,100	440	1340	61	36.0
KTJ25-41(D)	220/50	1150	4,100	460	1340	65	36.0
KTJ25-20	380/50	780	2,000	430	1340	55	28.4
KTJ25-26	380/50	805	2,600	410	1340	56	28.4
KTJ23-31	380/50	1150	3,100	440	1340	61	36.0
KTJ25-41	380/50	1150	4,100	460	1340	65	36.0
KTJ28-51	380/50	1050	5,100	400	940	67	55.8
KTJ32-61	380/50	1500	6,100	410	940	68	55.8
KTJ32-71	380/50	1955	7,100	440	940	67	62.6
KTJ32-81	380/50	2020	8,100	461	940	69	68.4
KTJ35-100	380/50	2530	10,000	551	940	70	84.0
KTJ35-120	380/50	3680	12,000	591	940	71	87.6
KTJ40-150	380/50	4140	15,000	700	940	75	115.0
KTJ40-200	380/50	6210	20,000	725	940	77	126.8
KTJ45-250	380/50	7856	25,000	740	940	79	126.2

Applications and Airflow Planning

Cabinet centrifugal fans can support fresh-air supply, exhaust systems, workshops, warehouses, commercial buildings and process ventilation where the duct system has meaningful resistance. Compare the MIWIND fresh-air system range when the project needs filtered outdoor air or coordinated supply equipment. For odor, heat or moisture removal, also review the exhaust fan range.

Installation and Control

Provide a rigid base or suitable support, connect the duct without loading the cabinet, and leave room for motor and impeller service. Check rotation, grounding, protective devices and the rated voltage before commissioning. A speed controller, damper or BMS signal should be selected for the motor and project control strategy. Confirm sound at the occupied location and use vibration isolation where required.

Request a Cabinet Fan Quote

Send the required airflow, estimated static pressure, duct size and route, voltage, sound limit, operating schedule and expected quantity through the MIWIND contact form for model selection and quotation support.
